UL3122 Fiberglass Braided Wire with 300V Rated Voltage and 200C High Temperature Silicone Rubber Insulation and Tinned Copper Conductor

  • UL3122 Fiberglass Braided Wire with 300V Rated Voltage and 200C High Temperature Silicone Rubber Insulation and Tinned Copper Conductor
  • UL3122 Fiberglass Braided Wire with 300V Rated Voltage and 200C High Temperature Silicone Rubber Insulation and Tinned Copper Conductor
  • UL3122 Fiberglass Braided Wire with 300V Rated Voltage and 200C High Temperature Silicone Rubber Insulation and Tinned Copper Conductor
  • UL3122 Fiberglass Braided Wire with 300V Rated Voltage and 200C High Temperature Silicone Rubber Insulation and Tinned Copper Conductor
  • UL3122 Fiberglass Braided Wire with 300V Rated Voltage and 200C High Temperature Silicone Rubber Insulation and Tinned Copper Conductor
  • UL3122 Fiberglass Braided Wire with 300V Rated Voltage and 200C High Temperature Silicone Rubber Insulation and Tinned Copper Conductor
Τόπος καταγωγής Γκουανγκντόνγκ, Κίνα
Μάρκα MYSUN
Πιστοποίηση ROHS/CCC/VDE/CCC/UL
Αριθμό μοντέλου ul3122
Ποσότητα παραγγελίας min 3050
Τιμή $0.18-0.65

Με ελάτε σε επαφή με δωρεάν δείγματα και δελτία.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

Εάν έχετε οποιαδήποτε ανησυχία, παρέχουμε τη 24ωρη σε απευθείας σύνδεση βοήθεια.

x
Λεπτομέρειες
Υλικό αγωγού Κονσερβοποιημένος χαλκός Διάμετρος 16 AWG, 18 AWG, 20 AWG, 22 AWG, 24 AWG, 1,25mm2, 0,5mm2, 0,75mm2, 1,5mm2
Μονωτικό Υλικό Καουτσούκ σιλικόνης Ονομαστική τάση 300V
Τύπος αγωγού Απομεμονωμένος Εκτίμηση θερμοκρασίας 200C
Μήκος μονάδας 305 μέτρο/ρόλος Μέγιστη αντίσταση στον αγωγό 143 Ω/KM (26 AWG), 89,3 Ω/KM (24 AWG), 56,4 Ω/KM (22 AWG), 35,2 Ω/KM (20 AWG), 22,2 Ω/KM (18 AWG), 1
Πάχος μόνωσης 0,60 mm (26 AWG), 0,65 mm (24 AWG) Διάμετρος αγωγού 0,48 mm (26 AWG), 0,61 mm (24 AWG), 0,77 mm (22 AWG), 0,94 mm (20 AWG), 1,19 mm (18 AWG), 1,49 mm (1
Συνολική διάμετρο 1,68 mm (26 AWG), 1,81 mm (24 AWG), 1,97 mm (22 AWG), 2,14 mm (20 AWG), 2,39 mm (18 AWG), 2,69 mm (1 Κατασκευή αγωγών 7/0,16 mm (26 AWG), 7/0,20 mm (24 AWG), 7/0,254 mm (22 AWG), 7/0,31 mm (20 AWG), 7/0,39 mm (18 AWG),
Μέτρημα κλώνου 7 κλώνοι (26-16 AWG), 1 κλώνοι (24-16 AWG), 11 κλώνοι (24 AWG), 17 κλώνοι (22 AWG), 26 κλώνοι (20 AW Επιφάνεια διατομής 0,30 mm², 0,50 mm², 0,75 mm², 1,00 mm², 1,25 mm²
Διάμετρος κλώνου 0,16 mm (26-18 AWG), 0,18 mm (0,30-1,25 mm²)
Επισημαίνω

300V Rated Voltage Fiberglass Braided Wire

,

200C High Temperature Silicone Rubber Wire

,

Tinned Copper Conductor UL3122 Wire
Αφήστε ένα μήνυμα
Περιγραφή προϊόντων
UL3122 300V 200°C Tinned Copper High Temperature Silicone Rubber Fiberglass Braided Motor Wire
Seeking Country Agents for a Win-Win Partnership
UL3122 Fiberglass Braided Wire with 300V Rated Voltage and 200C High Temperature Silicone Rubber Insulation and Tinned Copper Conductor 0
Product Specifications
Conductor Construction (No./mm) Diameter (mm) Nominal Thickness (mm) Diameter (mm) Max. Cond Resistance (Ω/KM) Unit Length (M)(Ft)
267/0.160.480.601.68143305/1000
247/0.200.611.8189.3
227/0.2540.771.9756.4
207/0.310.942.1435.2
187/0.391.192.3922.2
167/0.491.492.6914
241/0.500.500.651.8089.3305/1000
221/0.650.651.9556.4
201/0.810.812.1135.2
181/1.021.022.3222.2
161/1.201.202.5014
2411/0.160.610.601.8189.3305/1000
2217/0.160.761.9656.4
2026/0.160.942.1435.2
1841/0.161.182.3822.2
1626/0.2541.492.6914
0.30mm²12/0.180.710.601.9159.78305/1000
0.50mm²20/0.180.922.1240.1
0.75mm²30/0.181.132.3326.7
1.00mm²40/0.181.312.5120
1.25mm²50/0.181.462.6614.35
Click here to contact us for a competitive quote
Company Profile
UL3122 Fiberglass Braided Wire with 300V Rated Voltage and 200C High Temperature Silicone Rubber Insulation and Tinned Copper Conductor 1 UL3122 Fiberglass Braided Wire with 300V Rated Voltage and 200C High Temperature Silicone Rubber Insulation and Tinned Copper Conductor 2
Our Products
UL3122 Fiberglass Braided Wire with 300V Rated Voltage and 200C High Temperature Silicone Rubber Insulation and Tinned Copper Conductor 3
Applications
UL3122 Fiberglass Braided Wire with 300V Rated Voltage and 200C High Temperature Silicone Rubber Insulation and Tinned Copper Conductor 4
Our Overseas Clients
UL3122 Fiberglass Braided Wire with 300V Rated Voltage and 200C High Temperature Silicone Rubber Insulation and Tinned Copper Conductor 5
Exhibition
UL3122 Fiberglass Braided Wire with 300V Rated Voltage and 200C High Temperature Silicone Rubber Insulation and Tinned Copper Conductor 6
Certifications
UL3122 Fiberglass Braided Wire with 300V Rated Voltage and 200C High Temperature Silicone Rubber Insulation and Tinned Copper Conductor 7
Frequently Asked Questions
1. Who Are We?
We are a professional manufacturer of high-temperature wires and cables with 26 years of electric wire experience. Our headquarter is located in Shenzhen, Guangdong, China, and our two production bases are located in Dongguan, Guangdong, China and Jingzhou, Hubei, China.
2. What Can We Provide?
We can provide high-temperature wires and cables, silicone tubing - including silicone rubber wire, XLPE, FEP/PFA/ETFE/PTFE wire, new energy cable, wiring harnesses.
3. Why Choose Us?
A. Free Sample. B. Competitive Price. C. High Quality Standard. D. Customized Service.
4. What Certifications Do We Have?
We have UL, cUL, VDE, Reach, CE, ROHS, CCC, CQC Certification.
5. What Services Can We Provide?
Accepted Delivery Terms: FOB, CIF, EXW, FAS, CIP, FCA, DDP, DDU. Accepted Payment Currency: USD, EUR, CNY. Accepted Payment Type: T/T, L/C, PayPal, Western Union, Cash.
